3 million full-color PTZ wireless network camera

WA34 full-color

WA34 3MP Full-Color Network Camera the highest resolution is 2304 * 1296, with a clear real-time image output of 3 million pixels

Pan tilt rotation, with a horizontal viewing angle of 360 ° and a vertical viewing angle of 158 °

Intelligent motion detection, timely push of alarm information in case of abnormal situations

Support two-way voice calls, communication is barrier free

Supports up to 512GB Micro SD card with longer storage time

Supports three night vision modes: infrared night vision, full-color night vision, and motion detection full-color

Image and video parameters

Basic Parameters

Sensor type: 1/2.7-inch CMOS

Minimum illuminance: 0 1Lux@F2.1 (Color mode); 0.1Lux@F2.1 (Black and white mode); 0Lux (infrared light on)

Shutter: 1/25 second to 1/100000 second; Can be manually or automatically adjusted

Day night conversion mode: ICR infrared filter

Digital noise reduction: 3D noise reduction

Gain control: automatic

White Balance: Automatic

Backlight compensation: supported

Video Encoding Standards

Encoding standard: H.265

Encoding rate: 64Kbps~2Mbps

focal length

TL-IPC43AW full-color: 4mm

Lens parameters

Zoom type: fixed focus

Aperture control: fixed

Video parameters

Maximum image size: 2304 × 1296

Main stream: 2304 × 1296

Substream: 640 × 480

Video bitrate: H.265 bitrate adjustable

Image settings: adjustable saturation, brightness, contrast, sharpness, etc

Region of Interest (ROI): Supported

Conventional Parameters

interface

Wi Fi speed: 2.4GHz 150Mbps

Micro SD card interface: Supports

network function

Wi Fi speed: 2.4GHz 150Mbps

Intelligent alarm: motion detection, video occlusion

Conventional Parameters

Working temperature and humidity: Working temperature: -10 ℃~40 ℃, humidity less than 95% (no condensation)

Power supply: compatible with DC9V and 12V

Power consumption: 5.4W MAX

Size: 84mm × 84mm × 106.5mm

Weight: 210g
